Reverse Osmosis Desalination System BWRO 10tph-Morocco
Reverse osmosis (RO) desalination systems are advanced water treatment technologies designed to convert seawater or brackish water into freshwater by removing salts, minerals, and other impurities.
reverse osmosis desalination detailed parameter:
| HY-10m3ph | |||
| Flow rate | 10m3/hr | Recovery rate | 50% |
| Applicable power | 380V/50hz 3 phase | Rated power | 37.5KW |
| Feedwater TDS | ≤12000ppm | freshwater TDS | <200ppm |
| Working pressure | 30.8 bar | operating temperature | 5-45℃ |
| Feedwater residual chlorine | <0.1ppm | Feedwater SDI | <5 |
| Feedwater turbidity | <1NTU | Feedwater PH value | 7.9 |
| RO membrane housing | 8040*6 core,2ieces | RO membrane | 12 pieces |
| Equipment specification | 11*2*2.6(m) | Net weight | / |
| Packing specification(Plywood) | / | Gross weight | / |
If you want to watch more product videos, please click here!
If you want to learn more about the product , please click here!!
——————————————————————————————————————————————
What is BWRO system ?
Brackish water refers to water with a total dissolved solids (TDS) content ranging from 1,000 to 15,000 mg/L, including sources like groundwater, lakes, and rivers. BWRO systems utilize reverse osmosis (RO) technology to desalinate such water by applying pressure to force water molecules through a semipermeable membrane, effectively retaining salts, organics, and microorganisms.
| Application Area | Simple Use |
| Municipal Water Supply | Provide safe drinking water for coastal and inland water-scarce areas |
| Industrial Water Use | Treat high-salinity wastewater, supply boiler feedwater, and rinse electronic components |
| Agricultural Irrigation | Improve irrigation water quality and enhance fertilizer utilization efficiency when mixed with fertilizers |
| Energy Production | Supply high-quality demineralized water for power plants and other energy production facilities |
Industrial reverse osmosis desalination：
Industrial production processes require high-quality water, and reverse osmosis (RO) desalination systems effectively remove impurities and harmful substances to meet industrial water standards.
1.Chemical, Pharmaceutical, and Power Industries: Treat high-salinity wastewater, reclaim freshwater resources, and support enterprises in achieving zero-liquid discharge goals.
2.Boiler Feedwater: RO systems supply high-quality demineralized water to ensure the safe operation of boilers.
3.Electronics Industry Rinse Water: Used for rinsing integrated circuits, monocrystalline silicon, and other electronic components to ensure product quality.
we have real case about industrial reverse osmosis desalination system(click here)
——————————————————————————————————————————————
reverse osmosis desalination system Inquiry Guides:
To find the most appropriate system for your use, please ensure you have the following information ready.
·Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
·Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
·Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
·It is necessary to make water analysis reprot for borehole water,lake water, seawater.
·If soure water is tap water no need end to us TDS or water analysis report.
Quickly discuss and reply you.
