Industrial seawater reverse osmosis desalination system 1000m3pd-United Arab Emirates
Product Introduction：
The Industrial Seawater Reverse Osmosis Desalination System (SWRO), commercially viable since the early 1970s, is a versatile technology applied across scales from large-scale desalination plants to compact drinking water units. Initially, seawater undergoes pretreatment to remove particles, organics, and microbes, safeguarding downstream components. Subsequently, high-pressure pumps elevate water pressure to exceed osmotic gradients, driving reverse osmosis. In the membrane array, water molecules permeate semipermeable barriers, while salts and impurities are discharged as brine. Finally, the permeate undergoes post-treatment, including remineralization, pH adjustment, and disinfection, to ensure compliance with drinking water standards.
First of all, the typical single pass seawater treatment system consists of the following components:
Intake: direct from sea or beach well water
Pretreatment: Filtration and chemical dosing for example sand and carbon filter
High pressure pump: to achieve pressure for swro membrane filtration
Membrane assembly: to perform the desalination process for example DOW, Toray
pH adjustment: to adjust the alkalinity or acid level
Disinfection: to prevent any bacterial or organic growth for example uv sterilizer
Project Background:
Construction Location:
Within the premises of a coastal industrial enterprise in the UAE.
Seawater Desalination Capacity:
Daily freshwater production of 1,000 cubic meters (1,000 m³/d).
Operation Mode:
Continuous operation throughout the year to ensure stable water supply for the enterprise.
Technical Route:
Reverse Osmosis (RO) seawater desalination technology.
Seawater Pretreatment System
Design Capacity: 1,000 m³/d
Treatment Process: Multi-media filter + Ultrafiltration (UF) system+SWRO
Function: Removes suspended solids, colloids, bacteria, and other impurities from seawater to protect downstream RO membranes.
Reverse Osmosis Seawater Desalination System:
Membrane Modules: High-efficiency energy-saving RO membranes, with single-membrane desalination rate ≥99.5%.
Product Water Quality: TDS ≤500 mg/L (compliant with industrial water standards).
Recovery Rate: ≥45% (adjustable based on raw water quality and user demand).
Post-Treatment System
Water Quality Adjustment: Appropriate chemicals can be added to adjust water quality according to industrial requirements.
Storage & Water Supply: Equipped with industrial-grade storage tanks and pump sets to ensure stable water delivery.
Automation Control System
PLC Control: Enables automated equipment operation, including auto start/stop, parameter monitoring, fault alarms, and other functions.
Similar product video introduction：
Inquiry seawater ro system guides
To find the most appropriate system for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· TSS(Total Suspended Solid)
· SDI(Silting Density Index)< 3
·· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
· It is necessary to make water analysis reprot for borehole water,lake water, seawater.
· If soure water is tap water no need end to us TDS or water analysis report.
