Solar reverse osmosis water desalination system to make fresh water 1TPH
What is solar reverse osmosis water system?
A solar powered reverse osmosis water system is a device that uses solar energy as energy to remove impurities from water (such as seawater, brackish water, etc.) through reverse osmosis technology to produce fresh water.
The system integrates multiple technical links such as solar heat collection, power conversion and reverse osmosis membrane separation to achieve a green and sustainable process of extracting fresh water from water.
solar reverse osmosis water system function:
1.Provide fresh water supply:
By desalinating seawater or brackish water, it provides a sustainable source of fresh water for humans, alleviates the fresh water crisis, and meets the fresh water needs of industry, commerce, residents and other fields.
2.Respond to natural disasters:
After a natural disaster occurs, the system can quickly provide fresh water, support disaster relief and reconstruction work in the disaster area, and ensure the basic living needs of the affected people.
3.Improve water quality:
Remove harmful components in water, ensure drinking water safety, and improve people’s quality of life.
| HY-1000L/hr solar powered water purification | |||
| Flow rate | 1000L/hr | Recovery rate | 50% |
| Applicable power | 1PH x 220V, 50Hz | Rated power | 1.65KW |
| Solar powered | 35 KW | Inverter | 44KW |
| Solar panel | 14 PCS | Battery | 14PCS, 36KW |
| Incoming TDS | 80-100 ppm | output water TDS | <0.6ppm |
| Working pressure | 2.9 Bar | operating temperature | 5-45℃ |
| Feedwater residual chlorine | <0.1ppm | Feedwater SDI | <5 |
| Feedwater turbidity | <1NTU | Feedwater PH value | 6.5-7 |
| RO membrane housing | 4PCS 4040×1 cores | RO membrane | 4PCS |
| Variable-frequency Drive | For each pump | Container | No |
solar reverse osmosis water system Advantages:
1.Low operating cost:
Solar energy is free energy, so the solar-driven reverse osmosis water system can save a lot of energy costs in long-term operation.
2.Strong adaptability:
It is suitable for scenarios such as remote areas, islands, disaster areas, etc. where there is a lack of power supply, providing these areas with a reliable source of fresh water.
It can process water from different sources and different salinities, and has a wide range of adaptability.
3.Good water quality:
The reverse osmosis membrane has a high desalination rate and can effectively remove harmful components such as inorganic salts, heavy metal ions, organic matter, bacteria, etc. in the water. The fresh water produced is of excellent quality, even better than tap water.
4.Sustainability:
Solar energy is an inexhaustible and inexhaustible energy source with long-term sustainability, which enables the system to have a stable energy supply in long-term operation.
Application scenarios:
1.Industrial water:
Provide high-quality fresh water for industrial production and meet the water quality requirements of industrial production.
2.Agricultural irrigation:
Provide a stable irrigation water source for agricultural production and improve the efficiency and quality of agricultural production.
3.Remote areas:
In remote areas where there is a lack of power supply, the solar-driven reverse osmosis water system can operate independently and provide a reliable source of fresh water for local residents.
4.Islands:
Islands usually lack fresh water resources. This system is an important way to solve the fresh water problem, which helps the economic development of islands and improves the lives of residents.
5.Disaster areas:
After a natural disaster, the power supply may be interrupted. This system can be quickly deployed to provide much-needed fresh water to the disaster area.
6.Coastal water-scarce cities:
With the acceleration of urbanization, the demand for fresh water in coastal cities is increasing. This system can become an important supplement to urban water supply.
Haiyuan company also produce solar containerized reverse osmosis water treatment plant :
To find the most appropriate for your use, please advise the following information:
-Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
-Product water purpose(drinking, irrigation, industry process or others)
-Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
-Power (/380V/440V/460V, 50 or 60 Hz) 3 phase.
-It is necessary to make water analysis report for borehole water,lake water, seawater.
-If soure water is tap water no need water analysis report.
