Solar Containerized Reverse Osmosis System 3000LPH

Solar reverse osmosis system：

This solar mobile containerized reverse osmosis water system was ordered by a customer from Mozambique, who hoped to solve the problem of insufficient drinking water through this equipment and provide clean living water for the local community;We had in-depth discussions with the customer, hoping to give the customer a satisfactory and high-quality product to meet the customer’s needs. The customer was very satisfied with our equipment,whether it was quality, price, or service, so he trusted us and placed an order for 3 sets in total.

The role of high-quality accessories：

1.Feed water pump– provide the pressure to quartz sand filter/active carbon filter.2.Sands filter–get rid of turbidity, suspended matter, organic matter, colloid, ect.3.5μ Security filters –prevent large particles, bacteria, viruses into RO membrane, accuracy 5μm4.1μm Security filter– Prevent large particles, bacteria, viruses into RO membrane, accuracy 1μm

5.High pressure pump–Provide the high pressure to RO membrane ro.

6.RO system– main part of the plant. The RO membrane’s desalting rate can reach 99%, removing over 99% ions.

Haiyuan company’s high-quality products：

Haiyuan company produce Containerized reverse osmosis water treatment system if it needs mobility for your project. We can install RO Water Plant in 20ft or 40ft container and it allows you to save long term costs.
In container we can install pretreatment, reverse osmosis system. It is plug in system, just you need to join electrical power and piping. Inside of the container can be redecorate as optional.

HY-SCRO-3000L/hr (20m3/D)solar container reverse osmosis
Flow rate	20m3/day	Recovery rate	0.69
Applicable power	380V/50HZ 3 phase	Rated power	7.5KW
Solar powered	20KW	Inverter	20KW (25KVA)
Solar panel	20 pcs	Battery	8PCS, 24KW
Incoming TDS	2710ppm	output water TDS	50ppm
Working pressure	18 bar	operating temperature	5-45℃
Feedwater residual chlorine	<0.1ppm	Feedwater SDI	<5
Feedwater turbidity	<1NTU	Feedwater PH value	6.5-7
RO membrane housing	4040 x 2 cores 6pcs	RO membrane	12piece
Variable-frequency Drive	For each pump	Container	20FT

Facilities that can be included in the container：

-Solar panels （optional）
-New or second-hand (repaired, painted) container
-Water treatment system （Customize different capacities）
-Control panel
-Explosion proof lights
-Interconnecting piping between components and systems
-Instrument wiring and wiring inside the container to the main control cabinet accordingly
-Non-slip floor covering
-Air conditioning (optional)
-Insulating whiteboard (optional)
-Ventilation fans

Solar Powered Containerized reverse osmosis system have many advantages over built-in plant room installations:

Plug and play unit
Quick installation
Limited civil work (only container foundation)
Small foot print
Easy transportation
Mobile: useful for construction sites
Turnkey delivery: piping, cables, air conditioning

Solar power generation is an optional item.

If you want to learn about container water treatment plant

click the link below!

https://www.swroplant.com/case/container-ro-containerized-water-treatment-system/

—————————————-How to contact us and make inquiries ————————–

In order to send you correct information please tell me below information：

How many liters outlet water per hour do you require?(500L/H,1000L/H, etc.)
Where is the source water from? (Eg: well water/borehole water, river water. etc.)- Do you have water analysis result or know the water quality? (The TDS=total dissolved solid, Fe, Mg, Hardness etc. whether over proof etc).
After treated, the water meet WHO drinking water standard, or as per bottle water standard or other industrial purpose?
Your local power is 380V/50hz 3phase or 380V/60Hz 3 phase, 440/60hz 3 phase or other voltage?

BTW: If source water is Municipal tap water or clean reservoir water or spring water no need report. But please inform us the water characteristic.

Please contact us!

Email: Sales@seawaterroplants.com

Mob&WhatsApp&WhatChat: +86 18825874379

Solar Mobile water treatment systems based on different capacity and treated water standard or purpose. we will supply the Optimization solution for client.
